GPS+GSM天线
| |
|
 |
产品型号: GA-GPS/GSM-01
产 品 名: Combo Antenna
|
|
|
Size:
D71x14mm
Product Description::
SPECIFICATION
Size: D71x14mm
Dieletric Antenna
Center Frequency 1575.42 MHz±3 MHz
V.S.W.R 1.5 : 1
Band Width ±5 MHz
Impendence 50 ohm
Polarization Type RHCP
LNA / Filter
LNA Gain(Without cable) 30 dB Typical
Noise Figure 1.5 dB
DC Voltage 2.2~5 V
DC Current 5~15 mA
GSM Part
Frequency 824~894MHz/1710~1990MHz
880~960MHz/1710~1990MHz
V.S.W.R 2.0:1
Impendence 50 ohm
Typical Gain 2dBi
Cable RG174 3m/5m or others
Connector SMA/SMB/MCX or others
Working Temp -40'C~+85'C
Humidity 55%~75%RH
Waterproof IP67
|
